  • 4ch/8ch/16ch 1U/2U NVR: HK-NVR5204F, HK-NVR5208F, HK-NVR5216F,HK-NVR5232F


    1)4/8/16ch IP camera inputs
    2)1ch audio in & 1ch audio out
    3)Max 480fps@1080p recording
    4)ONVIF Version 2.0 conformance
    5)HDMI / VGA simultaneous video output
    6)Support 2 SATA HDDs up to 6TB, 2 USB2.0, 1RJ45(1000M)


    • Specifications


    4ch/8ch/16ch 1U/2U NVR

    Model number: HK-NVR5204F, HK-NVR5208F, HK-NVR5216D

    4ch nvr
    8ch nvr


      • 4chs/8chs/16chs IP camera inputs
      • 1ch audio in (For HK-NVR5216D only) & 1ch audio out
      • Max 480fps@1080p recording
      • ONVIF Version 2.0 conformance
      • HDMI / VGA simultaneous video output
      • Max support 2 SATA HDDs up to 8TB, 2 USB2.0, 1RJ45(1000M)
      • Multi-language Support(English, Finnish, French, German, Greek, Italian, Japanese, Polish, Portuguese, Russian, Spanish, Thai, Simplified Chinese, Chinese-Traditional, Turkish, etc)
      • Support KingCCTV cloud(,no need to do router mapping, just 1 step go to internet with KingCCTV cloud technology
      • Support multi-browser(IE, Chrome, Firefox, Safari)
      • support 3G & WIFI extension (For HK-NVR5216D only)
      • support P2P, cloud service


    Model No. HK-NVR5204F HK-NVR5208F HK-NVR5216D
    Main Processor Hi3520D
    Operating System Embedded Linux
    System resource Multi-channel real-time recording synchronously, multi-channel real-time playback, multi-channel multi-user network operation, USB back up.
    Operation interface 16 bit real color GUI interface support mouse operation
    Display screen 1/4 1/4/8/9 1/4/8/9/16
    Video standard PAL(625 lines, 50fps); NTSC(525lines, 60fps)
    Image encode H.264(High Profile)
    Monitor quality Monitor: D1; VGA: High Definition; HDMI: High definition
    Playback quality 1080P/D1
    Encode capability 1ch 1080P Realtime
    Motion detection Each channel can set 192(16*12) detection area
    Audio compression G711A
    Bidirectional talk support
    Record mode manual>alarm>motion detection>timing
    Local playback support 1*720P playback support 2*1080P playback support 2*960P playback
    Video search Time, date, event, channel search
    Space occupation Video: CIF 4~5G/day*chs, D1 16~20G/day*chs, 960H 12G~20G/day*chs; 720P 20~30G/day*chs; 1080P ~40G/day*chs
    audio: 691.2M/day*channel
    Video storage Local HDD, Network
    Back up mode Network backup, USB portable HDD, USB DVD/RW, SATA DVD/RW
    Video input 4chs 1080P,4chs D1 for Storage 8chs 1080P, 8chs 720P, 16chs D1 for Storage 16chs 960H for Storage
    Video output 1ch BNC, 1ch VGA, 1ch HDMI
    Video Loop out N/A
    Audio input N/A 1ch RCA
    Audio output 1ch RCA(200-3000mV, 5KΩ)
    Alarm input N/A
    Alarm output N/A
    Network interface RJ45 10M/100M self-adaptive Ethernet port
    PTZ control 1 RS485; support multi kinds of PTZ protocol
    USB port 2 * USB2.0
    HDD port 1 SATA port(1*4T) 2 SATA port(2*4T)
    Power 12V/2A
    Consumption less than 5W(not include H.D.D.)
    Working Temperature 0℃ ~ +55℃
    Working Humidity 10%~90%
    Dimension L233*W300*H45
    Weight 1.46KG

    *Design and specifications are subject to change without notice.
